Luminey MonaWall-SE5 – 5kWh Wall-Mounted Lithium Battery

Detailed Technical Specifications

General Overview

• Brand: Luminey
• Model: MonaWall-SE5
• Battery Type: LiFePO₄ (Lithium Iron Phosphate)
• System Type: Wall-Mounted Energy Storage Battery
• Application: Residential (Indoor & Outdoor)

Energy & Capacity

• Nominal Energy: 5 kWh
• Usable Energy: 5 kWh (100% DoD supported)
• Nominal Voltage: 51.2 V
• Voltage Range (Cut-off): 44.8 – 55.2 V

Performance & Current

• Rated Charge/Discharge Current: 50 A / 50 A (0.5C)
• Max Continuous Current: 100 A / 100 A (1C)
• Roundtrip Efficiency: >98%

🔁 Cycle Life & Durability

• Cycle Life: ≥6000 cycles
• Design Life: Long-term residential usage
• Depth of Discharge (DoD): 100% (full utilization)

Smart Features

• Built-in WiFi: Yes
• Mobile App Monitoring: Yes (remote control & tracking)
• Built-in Heater: Yes (better cold performance)
• Plug & Play Terminals: Quick DC connection system

Scalability

• Parallel Support: Up to 16 units
• Max System Capacity: 80 kWh

Communication

• Interfaces:
  • CAN 2.0
  • RS485

Safety & Design

• Anti-expansion design
• Advanced BMS protection
• High thermal stability (LFP chemistry)
• Strong enclosure for durability

Operating Conditions

• Installation: Indoor / Outdoor
• Charging Temperature: -10°C to +50°C
• Discharging Temperature: -20°C to +50°C
• Humidity: 10% – 95% (non-condensing)
• Altitude: <4000 m

Physical Specifications

• Dimensions (W × H × D): 544 × 524 × 162 mm
• Weight: 55 kg

Cooling & Protection

• Cooling Method: Natural convection
• Ingress Protection: IP65 (water & dust resistant)

Certifications

• IEC62619
• CE
• UN38.3
