Knox Combo Deal - 9C | Knox Krypton 13002 Solar Inverter | Knox Rackwall 10.5 Lithium Battery

Knox Krypton 13002 10kW Hybrid Solar Inverter:

The Knox Krypton 13002 is a 10kW hybrid solar inverter designed for high-demand residential and commercial energy systems. With intelligent load management, dual MPPT input, and full remote monitoring via Wi-Fi, it delivers powerful, flexible energy control. Its RGB lighting, wide PV input, and battery-independent operation make it a future-proof solution for clean energy users.

Key Features:

• Rated Power: 10kW

• Dual MPPT: Efficient tracking for two independent solar arrays

• Wide PV Input Range: 90VDC – 450VDC

• High PV Current: Up to 30A per MPPT

• Batteryless Operation: Run on solar + grid without batteries

• Dual AC Outputs:

  • Smart Load Output – Continuous power for essentials

  • Heavy Load Output – Shut off to conserve battery/solar

• 7” Touch HMI Screen: Full inverter control and visualization

• Built-in Wi-Fi Monitoring: Real-time tracking via mobile app

• USB OTG Support: For data and firmware upgrades

• DC Output Ports: Run low-voltage DC appliances directly

Knox Rackwall 10.5 Lithium Battery 51.2V 200Ah:

High-Capacity, Rack-Mount Battery for Energy Storage Systems

The LIO 10.5-IP20 is a robust, rack-mounted lithium-ion battery designed for advanced energy storage needs in residential and commercial solar systems. With a total capacity of 10.24kWh, this low-voltage battery uses long-life prismatic LiFePO₄ cells to ensure safety, scalability, and long-term performance.

Key Features:

• High Energy Storage: 10.24kWh total capacity (51.2V, 200Ah)

• Long Life: Over 6000 cycles (90% DoD @ 25°C); 10+ year calendar life

• Safe Chemistry: Prismatic LiFePO₄ cells with full protection suite (OVP, LVP, OCP, OTP, LTP, short-circuit)

• Smart BMS: Real-time monitoring, alarms, SOC display, and PC software support

• Flexible Installation: Standard 19” rack-mount design with quick-lock terminals

• Parallel Support: Expandable up to 15 batteries (not for series connection)

• User-Friendly Interface: 4.3" touch LCD screen for status, inverter protocol change, and diagnostics

• Wide Operating Range: Charge 055°C | Discharge -2055°C | Humidity 0–95% RH (non-condensing)

• Certifications:

  • Cell: IEC62619, UL1973, UL9540A, RoHS

  • Battery: UN38.3, CE, MSDS

• Communication Protocols: RS485 & CAN (for inverter), LINK-IN / LINK-OUT (for battery interconnection)
