Knox Combo Deal - 8C | Knox Krypton 12002 Solar Inverter | Knox Rackwall 8 Lithium Battery

Knox Krypton 12002 | 8.5kW Hybrid Solar Inverter:

High-Power Smart Inverter with Dual MPPT & Intelligent Load Control

The Knox Krypton 12002 is a next-generation 8.5kW hybrid solar inverter built for large homes and commercial spaces. With dual MPPT, advanced energy control, and real-time smart features, it offers maximum flexibility, battery independence, and future-ready integration—all in a sleek, touch-controlled design.

Key Features:

• Rated Power: 8.5kW

• Dual MPPT: Allows independent tracking of two PV arrays

• Wide PV Input Range: 90VDC – 450VDC

• High PV Input Current: Up to 30A per MPPT

• Batteryless Operation: Run directly on solar + grid power

• Dual AC Outputs:

  • Priority Load Output – Always powered

  • Heavy Load Output – Cut off during low power

• Built-in Wi-Fi: Real-time mobile monitoring via iOS & Android

• RGB Status Lights: At-a-glance system health indicators

• Touchscreen Control: Large 7” HMI display

• USB OTG Support: For firmware updates and data transfer

• Built-in DC Output: Run DC devices (fans, LEDs, routers) without external converters

Rackwall 8 | LIO 8.0-IP20 Lithium-ion Battery:

51.2V | 150Ah | 7.68kWh | LiFePO₄ | Rack-Mounted Energy Storage

The LIO 8.0-IP20 is a high-performance lithium-ion battery tailored for advanced energy storage applications. Designed with A-grade prismatic LiFePO₄ cells, it ensures outstanding safety, reliability, and long-term durability with over 6000 cycles at 90% depth of discharge.

Key Features:

• Energy Capacity: 7.68kWh (51.2V, 150Ah)

• Battery Chemistry: Long-life prismatic LiFePO₄ cells

• Cycle Life: Over 6000 cycles at 90% DoD (25°C, 0.5C)

• Mounting: Rack-mount (Standard 19”)

• Smart Protection: OVP, LVP, OTP, LTP, OCP, Short-circuit

• Display: 4.3" Touchscreen LCD + PC software

• Parallel Expansion: Supports up to 15 battery packs

• BMS Interface: RS485, CAN, LINK-IN, LINK-OUT

• Communication: Compatible with major inverter brands

• Operating Temp Range: -20°C to +55°C
