Knox Krypton 12002 | 8.5kW Hybrid Solar Inverter:
High-Power Smart Inverter with Dual MPPT & Intelligent Load Control
The Knox Krypton 12002 is a next-generation 8.5kW hybrid solar inverter built for large homes and commercial spaces. With dual MPPT, advanced energy control, and real-time smart features, it offers maximum flexibility, battery independence, and future-ready integration—all in a sleek, touch-controlled design.
Key Features:
-
Rated Power: 8.5kW
-
Dual MPPT: Allows independent tracking of two PV arrays
-
Wide PV Input Range: 90VDC – 450VDC
-
High PV Input Current: Up to 30A per MPPT
-
Batteryless Operation: Run directly on solar + grid power
-
Dual AC Outputs:
-
Priority Load Output – Always powered
-
Heavy Load Output – Cut off during low power
-
-
Built-in Wi-Fi: Real-time mobile monitoring via iOS & Android
-
RGB Status Lights: At-a-glance system health indicators
-
Touchscreen Control: Large 7” HMI display
-
USB OTG Support: For firmware updates and data transfer
-
Built-in DC Output: Run DC devices (fans, LEDs, routers) without external converters
Powerwall 6.0 | LIO 5.20-IP20 Lithium-ion Battery:
Key Features:
| Category | Details |
|---|---|
| Model | LIO 5.20-IP20 |
| Battery Type | LiFePO₄ |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Total Energy | 5120Wh |
| Configuration | 16S1P |
| Max Charge Voltage | 57.6V |
| Discharge Cut-off Voltage | 41.6V |
| Max Charge/Discharge Current | 100A |
| Peak Discharge Current | 120A @ 2s |
| Recommended Discharge Current | 100A |
| Recommended Depth of Discharge | 80% |
| Cycle Life | >6000 (80% DoD @ 25°C, 0.5C) |
| Display | LED |
| Communication Ports | RS485, RS232, CAN |
| Mounting | Wall-mounted |
| Enclosure Rating | IP20 |
| Terminal Type | M6 |
| Dimensions (L×W×H) | 533 × 500 × 150 mm |
| Weight | 45.1 ± 0.5 kg |
| Operating Temp. (Charge) | 0°C to +55°C |
| Operating Temp. (Discharge) | -20°C to +60°C |
| Storage Temp. (Optimal) | 5°C to 35°C |
| Humidity Range | 40% – 80% RH |
| Certifications | UN38.3, MSDS |
