Specifications:
| Specification | Details |
|---|---|
| Model | Knox PV6500 |
| Rated Power | 4500W (4.5KW) |
| PV Input Voltage Range | 120V – 450V DC |
| AC Output | 230V ± 5%, 50/60Hz |
| Waveform | Pure Sine Wave |
| Battery Support | Yes (Lithium/Ion/Lead Acid) |
| MPPT Efficiency | Up to 98% |
| Display | LCD Touch Screen |
| Cooling | Smart Ventilation (Side Fan) |
| Color | Purple-Black |
| Mounting Type | Wall-Mounted |
| Weight | Approx. 12-15kg |
The Knox Powerwall 3.0 LIO 2.56-IP20 is a next-generation wall-mounted lithium battery built using premium-grade prismatic LiFePO4 cells. Designed for residential solar systems, backup applications, and hybrid inverters, this unit ensures maximum safety, lifespan, and performance. With over 6000 cycles at 80% DOD, built-in BMS, and an informative LCD display, it delivers consistent power with minimal maintenance.
A-Grade Prismatic LiFePO4 Cells – Reliable and long-lasting
6000+ Cycle Life @80% DOD (0.5C, 25°C)
Built-in BMS – Overcharge, over-discharge, short circuit, high/low temp protection
LCD Display – Real-time monitoring of SOC, voltage, alarms, and temp
Cell Balancing Function – Improved battery health and cycle life
Sturdy Metal Enclosure – Enhanced heat dissipation and fire resistance
Certified Safe – UN38.3, MSDS approved
Scalable System – Max 2 in series, 4 in parallel
Communication Support – RS-485 port
Wall-Mounted Design – Easy installation, space-saving
