| Category | Specification |
|---|---|
| Model | LIO 2.66-IP20 |
| Battery Type | LiFePO₄ |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 100Ah |
| Total Energy | 2560Wh |
| Charge Voltage | 27.6V – 28.8V |
| Discharge Cut-off Voltage | 24V |
| Max Charge/Discharge Current | 100A |
| Pulse Discharge Current | 120A (2s) |
| Cycle Life | >6000 (80% DoD @ 25°C) |
| Designed Life | 10 years |
| Communication (Inverter) | RS485, CAN |
| Communication (Battery Link) | LINK-IN, LINK-OUT |
| Display | 4.3" Touch LCD |
| Protection | OVP, LVP, OCP, OTP, LTP, Short-circuit |
| Operating Temp. (Charge) | 0°C to +55°C |
| Operating Temp. (Discharge) | -20°C to +55°C |
| Humidity Range | 0–95% RH (non-condensing) |
| Mounting | Wall-mounted |
| Dimensions (W×D×H) | 395 × 470 × 160 mm |
| Weight | 28.0 kg |
| Parallel Support | Yes, up to 8 sets |
| Series Support | Not supported |
| Ingress Protection | IP20 |
| Certifications | UN38.3, MSDS, CE, IEC62619, UL1973, UL9540A, ROHS |
Smart Hybrid Inverter with Batteryless Operation & Dual Output
The Knox Krypton Eco 5000 is a 4.2kW smart hybrid solar inverter designed for modern solar systems. With support for batteryless operation, advanced MPPT solar control, dual AC output, and intelligent energy management, it’s ideal for homes and small businesses seeking reliable solar power with or without batteries.
Rated Power: 5000VA / 5000W
Batteryless Operation: Run directly on solar + grid without batteries
Pure Sine Wave Output: Safe for sensitive electronics
Dual Output Support:
Smart Load Output: Priority for essential loads
Heavy Load Output: Non-priority loads disconnected during outages
Advanced PV Controller: 18A MPPT charge controller with smart protections
Intelligent Load Management: Automatically balances power between grid, solar, and load
Grid Feed Support: Enables net metering (if available)
Battery Equalization: Improves performance & lifespan
Smart Battery Management System: Prevents overcharge, deep discharge & overheating
Anti-Dust Kit: Designed for harsh environments
