| Category | Details |
|---|---|
| Model | Xenon 12066 Hybrid Solar Inverter |
| Rated Output Power | 6.6kW |
| Maximum PV Input Power | Optimized with MPPT |
| Output Voltage | Pure sine wave, stable 220V-240V |
| Protection Rating | IP65 (Dust and Water Resistant) |
| Battery Compatibility | Batteryless operation supported, with BMS |
| Efficiency | Maximum energy harvest with advanced MPPT |
| Communication | WiFi, USB, RS232, RS485 for monitoring |
| Operating Temperature |
Built to perform in extreme climates |
| Battery Cell Technology | Lithium Iron Phosphate |
| Nominal Voltage | 51.2 V |
| Battery Capacity | 100Ah |
| Max. Continuous Charging / Discharging Current | 50A/100@25°C |
| Max. Charging Voltage | 57.6 V |
| Max. Discharging Voltage | 43.2 V |
| Max. Parallel Unit | 15 |
| Dimension,D X W X H (mm) | 140 x 450 x 500 |
| Net Weight (kg) | 43 |
| ENVIRONMENT | |
| Charge | 0°C~45°C |
| Discharge | -20°C~60°C (>45°C derating) |
| Operation Humidity | 5% ~ 95% RH (non-condensing) |
| Operation Air Pressure | 61 kPa~ 113 kPa |
| Lifecycle | 6000 cycles @80% 25°C | 4000 cycles @80% 35°C |
| MANAGEMENT | |
| IP Protection | IP20 |
| BMS Communication | RS485, RS232, CAN |
| Safety Standard | EN IEC 61000-6-3, EN IEC 61000-6-1, EN IEC 61000-3-2, IEC 61000-3-3, IEC 62619, UN38.3 |
