| Category | Details |
|---|---|
| Model | Xenon 12006 Hybrid Solar Inverter |
| Rated Output Power | 6.6kW |
| Maximum PV Input Power | Optimized with MPPT |
| Output Voltage | Pure sine wave, stable 220V-240V |
| Protection Rating | IP65 (Dust and Water Resistant) |
| Battery Compatibility | Batteryless operation supported, with BMS |
| Efficiency | Maximum energy harvest with advanced MPPT |
| Communication | WiFi, USB, RS232, RS485 for monitoring |
| Operating Temperature |
Built to perform in extreme climates |
| Category | Details |
|---|---|
| Model | LIO 5.20-IP20 |
| Battery Type | LiFePO₄ |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Total Energy | 5120Wh |
| Configuration | 16S1P |
| Max Charge Voltage | 57.6V |
| Discharge Cut-off Voltage | 41.6V |
| Max Charge/Discharge Current | 100A |
| Peak Discharge Current | 120A @ 2s |
| Recommended Discharge Current | 100A |
| Recommended Depth of Discharge | 80% |
| Cycle Life | >6000 (80% DoD @ 25°C, 0.5C) |
| Display | LED |
| Communication Ports | RS485, RS232, CAN |
| Mounting | Wall-mounted |
| Enclosure Rating | IP20 |
| Terminal Type | M6 |
| Dimensions (L×W×H) | 533 × 500 × 150 mm |
| Weight | 45.1 ± 0.5 kg |
| Operating Temp. (Charge) | 0°C to +55°C |
| Operating Temp. (Discharge) | -20°C to +60°C |
| Storage Temp. (Optimal) | 5°C to 35°C |
| Humidity Range | 40% – 80% RH |
| Certifications | UN38.3, MSDS |
