High-Capacity, Smart-Controlled Inverter for Home & Commercial Solar Systems
The Knox Krypton 15002 is a premium 11.5kW hybrid inverter built for larger homes and commercial energy systems. With intelligent load management, wide PV compatibility, and complete battery-independent operation, it’s an ideal solution for those looking to maximize solar efficiency and energy independence in Pakistan’s demanding power conditions.
Rated Power: 11.5kW
Dual MPPT: Supports two separate solar arrays for optimized tracking
Wide PV Input Range: 90VDC – 450VDC
High PV Input Current: 30A per MPPT channel
Batteryless Operation: Run with solar and grid even without batteries
Dual AC Outputs:
Essential Load Output – Continuous backup for critical appliances
Heavy Load Output – Automatically off during low solar/battery
7” HMI Touch Display: Easy monitoring and configuration
Built-in Wi-Fi: Mobile monitoring via app (Android/iOS)
USB OTG: For updates and data transfer
DC Output Support: Run low-voltage devices directly (LEDs, routers, etc.)
| Category | Details |
|---|---|
| Model | LIO 5.20-IP20 |
| Battery Type | LiFePO₄ |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Total Energy | 5120Wh |
| Configuration | 16S1P |
| Max Charge Voltage | 57.6V |
| Discharge Cut-off Voltage | 41.6V |
| Max Charge/Discharge Current | 100A |
| Peak Discharge Current | 120A @ 2s |
| Recommended Discharge Current | 100A |
| Recommended Depth of Discharge | 80% |
| Cycle Life | >6000 (80% DoD @ 25°C, 0.5C) |
| Display | LED |
| Communication Ports | RS485, RS232, CAN |
| Mounting | Wall-mounted |
| Enclosure Rating | IP20 |
| Terminal Type | M6 |
| Dimensions (L×W×H) | 533 × 500 × 150 mm |
| Weight | 45.1 ± 0.5 kg |
| Operating Temp. (Charge) | 0°C to +55°C |
| Operating Temp. (Discharge) | -20°C to +60°C |
| Storage Temp. (Optimal) | 5°C to 35°C |
| Humidity Range | 40% – 80% RH |
| Certifications | UN38.3, MSDS |
