Model: IPL-51314H

51.2V – 16kWh – 314Ah LiFePO4 Battery

Main Parameters

• Battery Type: LiFePO4

• Nominal Voltage: 51.2V

• Nominal Capacity: 314Ah

• Nominal Energy: 16kWh

• Operating Voltage Range: 43.2 – 57.6V

• Max. Parallel Units: 32

Charge Parameters

• Max. Continuous Charge Current: 157A

• Peak Charge Current: 175A @ 1s

Discharge Parameters

• Max. Continuous Discharge Current: 157A

• Peak Discharge Current: 175A @ 3s

• Max. Discharge Power: 16kW

• Recommended Depth of Discharge (DOD): 90%

Cycle Life

• >6000 cycles @25°C

• 0.5C charge / 0.5C discharge

• 80% DOD

• 80% End of Life (EOL)

Communication

• CAN 2.0 / RS485

General Specifications

• Dimensions (D × W × H): 230 × 548 × 840 mm

• Net Weight: 120 kg

• Operating Temp (Charge): 0°C to +60°C

• Operating Temp (Discharge): -20°C to +60°C

• Recommended Operating Temp: 15°C to +35°C

• Storage Temperature: 0°C to +35°C

• Humidity: 10% – 95%

• Max Altitude: 2000 m

• Ingress Protection: IP20

• Cooling Method: Natural Cooling

• Shell Material: Metal

• LED Display: 6 LED (SOC) + 2 LED (Run & Alarm)

• Certification: IEC62619 / UN38.3 / MSDS / DGM

Protection Features

• Circuit Breaker: Yes

• Voltage Protection: Yes

• Current Protection: Yes

• Temperature Protection: Yes

• Short Circuit Protection: Yes
