Zapher 6.6kW Single Phase Hybrid Inverter:
Single Phase Hybrid Inverter with Grid Feeding & IP66 Protection
Key Features:
- Rated Output Power: 6600W
- Max. PV Input Power: 12000W
- Dual MPPT (2 trackers)
- Dual Input (GEN/AC) for automatic switching between generator and utility mains
- In-built WiFi + HMI touchscreen
- Parallel operation with up to 9 units
- IP65 & IP66 waterproof and dustproof design
- Battery-independent design
- Dual output for smart load management
Technical Specifications:
PV Input
- Max. PV Array Open Circuit Voltage: 500 VDC
- MPPT Operating Voltage Range: 120–450 VDC
- Max. PV Array Current per MPPT: 2×21A
- Max. PV Array Isc per MPPT: 28.7A
- Number of MPPT Trackers: 2
Grid Output (AC)
- Nominal Output Voltage: 220/230/240 VAC
- Nominal Output Current: 26.25A
- Feed-in Grid Voltage Range (Pakistan): 182–260 VAC
- Feed-in Grid Frequency Range (Pakistan): 45.1–54.9Hz
- Power Factor Range: >0.99
- Max. Conversion Efficiency (DC/AC): 97%
Grid Input
- Acceptable Input Voltage Range: 90–300 VAC
- Frequency Range: 50Hz/60Hz (auto sensing)
- Transfer Time: <20ms (home appliances), <50ms (parallel operation)
- AC Transfer Relay Rating: 60A
Generator Input
- Acceptable Input Voltage Range: 90–290 VAC or 170–290 VAC
- AC Transfer Relay Rating: 40A
Battery Mode Output (AC)
- Nominal Output Voltage: 220/230/240 VAC
- Output Waveform: Pure Sine Wave
- Efficiency (DC to AC): 93%
Battery & Charger
- Nominal DC Voltage: 48 VDC
- Max. Charging Current (Grid): 135A
- Max. Charging Current (PV): 135A
- Max. Discharging Current: 135A
General
- Dimensions (D x W x H): 435 x 325 x 171 mm
- Net Weight: 16 kg
- Parallel-able: Yes
- External Safety Box: Optional
- Communication: USB/RS232, WiFi, BMS RS485, CAN-BUS
- Operating Temperature: -25°C to 50°C
- Humidity: 0–95% RH (non-condensing)
