Knox PowerBase 16 51.2v 314A Lithium Battery
Download Product Datasheet KNOX Powerbase 16 16.08kWh 51.2V 314Ah LiFePO4 Lithium Battery Description The KNOX Powerbase 16...
- Rs.575,000.00
Rs.595,000.00- Rs.575,000.00
- Unit price
- per
Please hurry! Only 10 left in stock
Subtotal:
Rs.575,000.00
10 customers are viewing this product
Couldn't load pickup availability
Shipping
You have to pay Partial Payment for order confirmation
Estimated Shipping Time: 24 to 72 Hours
100% Original & Official Product
KNOX Powerbase 16 16.08kWh 51.2V 314Ah LiFePO4 Lithium Battery
Description
The KNOX Powerbase 16 is a high-capacity 16.08kWh LiFePO4 lithium battery designed for residential and commercial solar energy storage applications. It uses brand-new prismatic LiFePO4 cells and a 51.2V 314Ah configuration, providing reliable energy storage with a long service life of more than 8,000 cycles.
The battery features a 4.3-inch HMI touchscreen, PACE BMS, cell balancing, comprehensive battery protection, and a durable metal enclosure for improved heat dissipation and safety. Up to 8 batteries can be connected in parallel, allowing the storage system to be expanded when higher capacity is required.
Key Features
- 16.08kWh nominal energy capacity
- 51.2V nominal voltage
- 314Ah nominal capacity
- Premium prismatic LiFePO4 cells
- More than 8,000 cycles
- 0.6C recommended charge/discharge rate
- PACE BMS
- Cell balancing function
- 4.3-inch HMI touchscreen
- Comprehensive overcharge, over-discharge and over-temperature protection
- Over-current and short-circuit protection
- Metal enclosure for improved heat dissipation
- Up to 8 batteries can be connected in parallel
- RS485 and RS232 communication
- Quick-plug connection
- IP20 protection
- 5-year warranty
- UN38.3 and MSDS certified
Product Specifications
| Specification | Details |
|---|---|
| Brand | KNOX |
| Model | Powerbase 16 |
| Battery Type | LiFePO4 |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 314Ah |
| Energy Capacity | 16,076Wh / 16.08kWh |
| Charge Cut-off Voltage | 57.6V |
| Discharge Cut-off Voltage | 41.6V |
| Maximum Charge Current | 150A |
| Continuous Discharge Current | 200A |
| Peak Discharge Current | 360A @ 10 seconds |
| Recommended Discharge Current | 150A |
| Charge & Discharge Rate | 0.6C |
| Cycle Life | >8,000 cycles |
| Parallel Capability | Up to 8 units |
| Communication | RS485 / RS232 |
| Display | HMI Touchscreen |
| Charge Temperature | 0°C to +55°C |
| Discharge Temperature | -20°C to +60°C |
| Storage Temperature | -5°C to +45°C, depending on storage period |
| Relative Humidity | 60% ±20% RH |
| IP Rating | IP20 |
| Connection | Quick Plug |
| Dimensions (L × W × H) | 520 × 245 × 880mm |
| Weight | 119.5kg |
| Certification | UN38.3 / MSDS |
| Warranty | 5 Years |
The electrical and mechanical specifications above are taken from the KNOX Powerbase 16 technical datasheet.
Product Details
The KNOX Powerbase 16 16.08kWh Lithium Battery is built for high-capacity energy storage where safety, scalability and long-term performance are important. Its 314Ah LiFePO4 battery bank provides substantial energy storage, while the PACE BMS continuously manages and protects the battery.
With support for up to 8 units in parallel, the Powerbase 16 can be scaled for larger solar installations. The integrated HMI touchscreen provides convenient system status monitoring, while RS485 and RS232 communication interfaces enable integration with compatible energy-storage systems.
