Krypton 11008 8kW Hybrid Solar Inverter with Grid Feeding (PV12000 Twin MPPT)

Key Features:

• 8kW rated output power

• Supports up to 12,000W solar PV input

• Dual MPPT with 22A input current per tracker

• Wide PV voltage range: 90VDC–450VDC

• Battery-independent operation

• Grid-feeding functionality

• Intelligent dual output for smart load management

• Built-in Wi-Fi for remote monitoring via Android and iOS

• Large touchscreen HMI display with RGB status indicators

• USB OTG firmware upgrade support

• Configurable AC and PV output priority

• Compatible with utility grid and generator input

• Built-in anti-dust protection

• Optional CT function for self-consumption

• Parallel operation with up to 9 inverters

• Replaceable cooling fan for easy maintenance

• Reserved BMS communication ports (RS485, CAN Bus, RS232)

Technical Specifications

PV Input

• Maximum PV Input Power: 12,000W

• Maximum DC Voltage: 500VDC

• MPPT Voltage Range: 120VDC–430VDC

• Start-up Voltage: 120VDC

• Initial Feeding Voltage: 150VDC

• MPPT Trackers: 2

• Maximum Input Current: 2 × 22A

• Maximum Short Circuit Current: 2 × 30A

AC Output

• Rated Output Power: 8,000W

• Output Voltage: 220V / 230V / 240V AC

• Nominal Output Current: 34.8A

• Pure Sine Wave Output

• Power Factor: Greater than 0.99

• Maximum Conversion Efficiency: 95%

• DC to AC Efficiency: 93%

Battery & Charging

• Battery Voltage: 48VDC

• Floating Charge Voltage: 54VDC

• Overcharge Protection: 63VDC

• Solar Charging Current: Up to 150A

• AC Charging Current: Up to 120A

• Maximum Charging Current: 120A

Backup Performance

• Surge Power: 13,000VA

• Transfer Time:

  • 10ms for computers

  • 20ms for home appliances

Communication

• Built-in Wi-Fi

• USB

• RS232

• RS485

• Dry Contact

• BMS Communication Support

Physical Specifications

• Dimensions: 140 × 295 × 468 mm

• Weight: 13.5 kg

Operating Conditions

• Operating Temperature: -10°C to 50°C

• Storage Temperature: -15°C to 60°C

• Humidity: 0–90% RH (Non-condensing)

Certification

• IEC 62109-1

• IEC 62109-2

• IEC 61683

• IEC 61682

• Low Voltage Directive 2014/35/EU

Powerbase 32 - 51.2V 628Ah LiFePO4 Battery

Key Features

• A-Grade Prismatic LFP Cells - Brand new cells with built-in cell balancing for consistent performance
• 8000+ Cycle Life - Built to last, with a 5-year manufacturer warranty
• PACE BMS Protection - Guards against overcharge, over-discharge, overheating, low temperature, overcurrent, and short circuits
• 4.3" HMI Touchscreen - Low power consumption, high brightness, and clear visibility from a distance
• Parallel Connection - Connect up to 8 units together for expanded capacity
• Metal Casing - Durable design with excellent heat dissipation for added safety
• Certified Safety - UN38.3 and MSDS certified

Technical Specifications

Electrical Parameters

Performance

Environmental Parameters

Mechanical Parameters
