Knox Azadi Sale Offer - AZ-24 | Knox PowerBase 32 Lithium Battery | Knox Krypton 9055 Solar Inverter

Knox Azadi Sale Offer - AZ-24 | Knox PowerBase 32 Lithium Battery | Knox Krypton 9055 Solar Inverter

KNOX Krypton 9055:Technical Specifications: Parameter Details Model 6.5kW-48-PV9055-TWIN Phase Single Phase Rated Output Power 6500W PV +...
Vendor: Knox
Availability: In stock
Rs.1,256,700.00
Rs.1,285,000.00
Rs.1,256,700.00
Please hurry! Only 5 left in stock
Subtotal: Rs.1,256,700.00
Order on WhatsApp
10 customers are viewing this product

Shipping

You have to pay Partial Payment for order confirmation

Estimated Shipping Time: 24 to 72 Hours

100% Original & Official Product

Knox Azadi Sale Offer - AZ-24 | Knox PowerBase 32 Lithium Battery | Knox Krypton 9055 Solar Inverter

Knox Azadi Sale Offer - AZ-24 | Knox PowerBase 32 Lithium Battery | Knox Krypton 9055 Solar Inverter

Rs.1,285,000.00 Rs.1,256,700.00
Knox Azadi Sale Offer - AZ-24 | Knox PowerBase 32 Lithium Battery | Knox Krypton 9055 Solar Inverter

Knox Azadi Sale Offer - AZ-24 | Knox PowerBase 32 Lithium Battery | Knox Krypton 9055 Solar Inverter

Rs.1,285,000.00 Rs.1,256,700.00
Description

KNOX Krypton 9055:
Technical Specifications:

Parameter Details
Model 6.5kW-48-PV9055-TWIN
Phase Single Phase
Rated Output Power 6500W
PV + Battery Output 8000W
Max PV Input Power 4500W x 2
Max PV Input Current 2x22A
PV Voltage Range 120–430VDC
Nominal DC Voltage 48VDC
Max Solar Charging Current 150A
AC Charging Current 120A
Surge Power 13000VA
Output Voltage 220/230/240 VAC
Output Waveform Pure Sine Wave
Transfer Time 10ms (PCs), 20ms (Home Appliances)
Efficiency DC-AC: 93% / MPPT: 95%
Communication Ports USB, RS232, RS485, WiFi, Dry-contact
Dimensions (D x W x H) 140 x 295 x 468 mm
Net Weight 13.5 kg
Operating Temp. -10°C to 50°C
Humidity 0 ~ 90% RH (non-condensing)
Certifications IEC 62109-1/-2, IEC 61683, LVD 2014/35/EU



Powerbase 32 - 51.2V 628Ah LiFePO4 Battery

Key Features

  • A-Grade Prismatic LFP Cells - Brand new cells with built-in cell balancing for consistent performance
  • 8000+ Cycle Life - Built to last, with a 5-year manufacturer warranty
  • PACE BMS Protection - Guards against overcharge, over-discharge, overheating, low temperature, overcurrent, and short circuits
  • 4.3" HMI Touchscreen - Low power consumption, high brightness, and clear visibility from a distance
  • Parallel Connection - Connect up to 8 units together for expanded capacity
  • Metal Casing - Durable design with excellent heat dissipation for added safety
  • Certified Safety - UN38.3 and MSDS certified

Technical Specifications

Electrical Parameters

Spec Value
Battery Type LiFePO4 (LFP)
Nominal Voltage 51.2 V
Nominal Capacity 628 Ah
Energy 32,153.6 Wh
Charge Cut-off Voltage 58.4 V
Discharge Cut-off Voltage 43.2 V
Open Circuit Voltage 50.88 ~ 53.6 V
Max. Charge Current 150 A
Max. Discharge Current 150 A
Continuous Discharge Current 300 A
Recommended Discharge Current 300 A
Peak Discharge Current 400 A (500ms)
Charge/Discharge Rate 0.5C

Performance

Spec Value
Cycle Life 8000+ cycles
Warranty 5 years
Parallel Units Up to 8
Communication RS485, RS232, CAN
Display 4.3" HMI Touchscreen

Environmental Parameters

Spec Value
Charge Temperature 0°C ~ +55°C
Discharge Temperature -20°C ~ +60°C
Storage Temperature -5°C ~ 0°C / 35°C ~ 45°C (up to 2 months); 5°C ~ 35°C (up to 3 months, optimum); 15°C ~ 35°C (up to 6 months)
Relative Humidity 60% ± 20% RH
Ingress Protection IP20

Mechanical Parameters

Spec Value
Connection Terminal Quick Plug
Dimensions (L x W x H) 760 x 400 x 760 mm
Weight 248 kg
Certificates UN38.3, MSDS
Warranty 5 years
