Knox Azadi Sale Offer - AZ-22 | Knox PowerBase 32 Lithium Battery | Knox Krypton Eco 6600 Solar Inverter

Knox Azadi Sale Offer - AZ-22 | Knox PowerBase 32 Lithium Battery | Knox Krypton Eco 6600 Solar Inverter

Knox Krypton Eco 6600 Hybrid Solar Inverter: Technical Specifications: Specification Details Model Krypton Eco 6600 Rated Power...
Vendor: Knox
Availability: In stock
Rs.1,202,000.00
Rs.1,230,000.00
Rs.1,202,000.00
Please hurry! Only 5 left in stock
Subtotal: Rs.1,202,000.00
Order on WhatsApp
10 customers are viewing this product

Shipping

You have to pay Partial Payment for order confirmation

Estimated Shipping Time: 24 to 72 Hours

100% Original & Official Product

Knox Azadi Sale Offer - AZ-22 | Knox PowerBase 32 Lithium Battery | Knox Krypton Eco 6600 Solar Inverter

Knox Azadi Sale Offer - AZ-22 | Knox PowerBase 32 Lithium Battery | Knox Krypton Eco 6600 Solar Inverter

Rs.1,230,000.00 Rs.1,202,000.00
Knox Azadi Sale Offer - AZ-22 | Knox PowerBase 32 Lithium Battery | Knox Krypton Eco 6600 Solar Inverter

Knox Azadi Sale Offer - AZ-22 | Knox PowerBase 32 Lithium Battery | Knox Krypton Eco 6600 Solar Inverter

Rs.1,230,000.00 Rs.1,202,000.00
Description

Knox Krypton Eco 6600 Hybrid Solar Inverter:

Technical Specifications:

Specification Details
Model Krypton Eco 6600
Rated Power 6600W / 6600VA
Surge Capacity 18,000VA
Battery Voltage 48VDC
Max. Charging Current 100A (80A Solar + 80A AC Input)
PV Input Range 30V – 400V
Efficiency 93%
Output Type Dual Output for Load Management
Communication Ports RS232 / RS485 / Optional WiFi
BMS Support Yes
Dimensions (mm) 115 × 300 × 435
Weight 10.4 kg


Powerbase 32 - 51.2V 628Ah LiFePO4 Battery

Key Features

  • A-Grade Prismatic LFP Cells - Brand new cells with built-in cell balancing for consistent performance
  • 8000+ Cycle Life - Built to last, with a 5-year manufacturer warranty
  • PACE BMS Protection - Guards against overcharge, over-discharge, overheating, low temperature, overcurrent, and short circuits
  • 4.3" HMI Touchscreen - Low power consumption, high brightness, and clear visibility from a distance
  • Parallel Connection - Connect up to 8 units together for expanded capacity
  • Metal Casing - Durable design with excellent heat dissipation for added safety
  • Certified Safety - UN38.3 and MSDS certified

Technical Specifications

Electrical Parameters

Spec Value
Battery Type LiFePO4 (LFP)
Nominal Voltage 51.2 V
Nominal Capacity 628 Ah
Energy 32,153.6 Wh
Charge Cut-off Voltage 58.4 V
Discharge Cut-off Voltage 43.2 V
Open Circuit Voltage 50.88 ~ 53.6 V
Max. Charge Current 150 A
Max. Discharge Current 150 A
Continuous Discharge Current 300 A
Recommended Discharge Current 300 A
Peak Discharge Current 400 A (500ms)
Charge/Discharge Rate 0.5C

Performance

Spec Value
Cycle Life 8000+ cycles
Warranty 5 years
Parallel Units Up to 8
Communication RS485, RS232, CAN
Display 4.3" HMI Touchscreen

Environmental Parameters

Spec Value
Charge Temperature 0°C ~ +55°C
Discharge Temperature -20°C ~ +60°C
Storage Temperature -5°C ~ 0°C / 35°C ~ 45°C (up to 2 months); 5°C ~ 35°C (up to 3 months, optimum); 15°C ~ 35°C (up to 6 months)
Relative Humidity 60% ± 20% RH
Ingress Protection IP20

Mechanical Parameters

Spec Value
Connection Terminal Quick Plug
Dimensions (L x W x H) 760 x 400 x 760 mm
Weight 248 kg
Certificates UN38.3, MSDS
Warranty 5 years
