High-Efficiency | IP66 Rated | Commercial-Grade Performance
Quick installation with standard tools
Smart setup & monitoring via Ai Solar App
150% PV oversizing (up to 60,000 Wp)
4 MPPT inputs for maximum solar harvesting
IP66 – Suitable for both indoor & outdoor use
ShadeSol technology for better performance in partial shading
Wide MPPT voltage range: 180V – 1000V
Compact wall-mount bracket
International certifications: IEC62109-1, IEC62116, etc.
Rated AC Power: 40,500 W
Rated Apparent Power: 40,500 VA
PV Input Capacity (STC): 60,000 Wp
AC Nominal Voltage: 230V / 400V (Three Phase)
Rated Output Current: 63.8 A
AC Voltage Range: 160V – 300V
AC Grid Frequency: 50 Hz (45–55 Hz)
MPPT Inputs / Strings per MPPT: 4 / (A:2, B:2, C:1, D:1)
Max Efficiency: 98.7%
European Efficiency: 98.3%
Power Factor Range: 0.8 leading to 0.8 lagging
THD: < 3%
Protection: IP66, DC Switch, Reverse Polarity, Anti-Islanding, Residual Current Monitoring
Cooling: Active cooling
Self Consumption (Night): < 1W
Dimensions (W x H x D): 574 × 513.5 × 234.5 mm
Weight: 29.5 kg
Communication Interfaces: RS485 / Wi-Fi / LAN / 4G
