| Specification | Details |
|---|---|
| Model | LX A5.0-30 |
| Battery Type | LFP (LiFePO4) |
| Nominal Battery Energy | 5.12kWh |
| Usable Energy | 5kWh |
| Operating Voltage Range | 43.20V ~ 58.24V |
| Nominal Charge Current | 60A |
| Max Continuous Charge Current | 90A |
| Nominal Discharge Current | 100A |
| Max Continuous Discharge Current | 150A |
| Max Pulse Discharge Current | <200A (30s) |
| Max Continuous Discharge Power | 7200W |
| Discharge Rate | 1.5C |
| Communication | CAN |
| Round-trip Efficiency | ≥96% |
| Cycle Life | 6000 Cycles @ 25°C, 0.2C, 70%EOL |
| Operating Temperature | Charge: 0°C ~ 55°C, Discharge: -20°C ~ 55°C |
| Max Storage Time | 12 Months (Maintenance-free) |
| Max Operating Altitude | 4000m |
| Weight | 44 KG |
| Dimensions (Core Part) | 442 × 133 × 520 mm |
| Dimensions (Maximum) | 483 × 133 × 559 mm |
| Protection Rating | IP20 |
| Applications | On-Grid / On-Grid + Backup / Off-Grid |
| Scalability | Up to 30 Units Parallel (150kWh) |
| Mounting Methods | 19-inch Rack / Floor / Wall Mount |
| Safety Certifications | IEC62619, IEC63056, N140 |
| EMC Standards | EN IEC 61000-6-1 / 6-2 / 6-3 / 6-4 |
| Transportation Certification | UN38.3, ADR |
| Environmental Standard | ROHS |
