Crown Solar Energy Elektra Boost Pro 5.12kWh 51.2V 100Ah Lithium Battery

Description

The Crown Solar Energy Elektra Boost Pro 5.12kWh 51.2V 100Ah Lithium Battery is a high-performance energy storage solution designed for residential and commercial solar energy systems. Built with advanced LFP (LiFePO₄) battery cells, it provides safe, reliable, and efficient energy storage with a cycle life of more than 6,000 charge-discharge cycles.

With a 5.12kWh rated energy capacity, 100Ah capacity, and 51.2V nominal voltage, the Elektra Boost Pro supports up to 5.12kW maximum charging and discharging power. Its modular design allows up to 15 battery modules to operate in parallel, providing flexible system expansion for different energy storage requirements.

The battery offers excellent compatibility with single-phase, three-phase hybrid, and retrofit inverter systems. Supporting RS485, RS232, and CAN communication, it can integrate efficiently with compatible energy management systems.

Key Features

• 5.12kWh rated energy capacity
• 4.6kWh usable energy at 90% DOD
• 100Ah rated capacity
• 51.2V nominal voltage
• Advanced LFP (LiFePO₄) battery technology
• More than 6,000 charge-discharge cycles
• 1C charge/discharge rate support at 25°C
• Maximum 100A charging/discharging current
• Maximum 5.12kW charging/discharging power
• Compatible with single-phase, three-phase hybrid, and retrofit inverter systems
• Up to 15 battery modules can be connected in parallel
• RS485, RS232, and CAN communication
• Natural convection cooling
• Wall-mounted or floor-stand installation
• IP21 protection rating
• CE, IEC62619, and UN38.3 certified

Product Specifications

Product Details

The Crown Solar Energy Elektra Boost Pro 5.12kWh 51.2V 100Ah Lithium Battery is engineered for dependable and efficient energy storage. Its LFP chemistry provides a safe and reliable battery platform, while its more than 6,000-cycle lifespan supports long-term solar energy storage applications.

The battery provides 5.12kWh rated energy and 4.6kWh usable energy, with a 51.2V nominal voltage and 100Ah capacity. It supports a recommended 50A charge/discharge current and can deliver up to 100A and 5.12kW at maximum charge/discharge conditions.

For system expansion, up to 15 battery modules can be connected in parallel. The battery supports RS485, RS232, and CAN communication and can be installed using either a wall-mounted or floor-stand configuration.

The Crown Solar Energy Elektra Boost Pro is designed for indoor installation and features IP21 protection, natural convection cooling, and an operating temperature range of 0°C to +55°C for charging and -20°C to +55°C for discharging.

Note: Crown Solar Energy recommends 50A at 2.5kW for maximum battery module lifetime. Maximum charging/discharging current and power may be derated depending on temperature and state of charge (SOC).
